The two opening ways for medium flowing in and out are at the same direction, forming an angle of 180°. This kind of globe valve makes the destructiveness of flowing state be relative less, thus reducing the pressure loss caused by the vale correspondingly.
- Design standard as per: BS1873、GB/T 12235
- Generally, lift is just 1/4 of the valve seat port, ensuring a short Opening/closing time.
- Only one sealing face exists on the valve body and disc.
- For large size valves will be designed with main disc and vice disc type, and medium flow from up disc to down disc.
- The valve is designed as a back seat sealing structure.
- Use flexible and woven graphite collaboration type packing
Body material: carbon steel, stainless steel, alloy steel
Nominal diameter: : 1/2"～24"（DN15~DN600）
End Connection: RF, RTJ, BW
Pressure range: :Class150～2500（PN10~PN420）
Working temperature:-29℃～560℃
Operation:handwheel, gear box, electric, etc.
